Fluid Solenoid Valve

Timer Solenoid Timer Electric Motor

Quantity(pieces)    1 – 10    11 – 100    101 – 500    >500
Est. Time(days)    7    10    15    To be negotiated

2V SERIES 2/2 WAY SOLENOID VALVE

Morking Medium Air,Water,Oil
Type Normal Close Type
Operation Fluid Viscosity 20 CST (Below)
Operating Temperature Range -10~+80
Voltage Range 10%
Protect Class IP65

Solenoid Valves for Industrial and Process applications full range of direct operated solenoid valves, from 1/8″ to 1/2″, offering many sealing materials and different flow rates.
The Heavy Duty Poppet valves use the well proven poppet principle to give high flow rates with short valve travel. Both the 2/2 and 3/2 valves in the range are available in G1/8″ and G1/2″ post sizes. All valves are normally closed.

2W/2S NORMAL OPEN SERIES SOLENOID VALVE

Working Medium Air,Water,Oil,Gas
Motion Pattern Direct Drive Type
Type Normal Open Type
Operation Fluid Viscosity 20 CST(Below)
Max Pressure Resistance 1.05MPa
Operating Temperature Range ‐5～+80℃

Solenoid Valves for Industrial and Process applications full range of direct operated solenoid valves, from 1/8″ to 1/2″, offering many sealing materials and different flow rates.
The Heavy Duty Poppet valves use the well proven poppet principle to give high flow rates with short valve travel. Both the 2/2 and 3/2 valves in the range are available in G1/8″ and G1/2″ post sizes. All valves are normally closed.

XCP SERIES PLASTIC ACTUATOR BEVEL VALVE

Angle seat valve VZXF
The rugged, all-purpose VZXF angle seat valve is ideal for any application requiring open-loop control of media flows—whether gaseous, liquid, or highly viscous.
Sturdy design
Stainless steel and gunmetal process valves with stainless steel, brass, or aluminum actuators
Different actuator sizes and housing materials
Selection of different seat and shaft seals
For liquids, gases, and other easily contaminated media
Easy-to-clean design

Port Size G1/4” ~G3”
KV Value(M3/h) 3.7~135
Actuator 40~100
Medium Temperature -10~+180℃
Flow Direction A(Flow Direction Below The Seat)or B(Flow Direction

Structural design Poppet valve with piston actuator
Actuation type Pneumatic
Sealing principle Soft
Type of mounting Line installation
Cable connection Threaded sleeve 1 NPT as per ANSI/ASME B 1.20.1
Nominal width 13 mm
Valve function 2/2, closed, monostable
Flow direction Non-reversible
Medium pressure 0 MPa … 4 MPa
Medium pressure 0 bar … 40 bar
Nominal pressure of fitting PN 40
Exhaust air function Without flow control option
Reset method Mechanical spring
Type of control Externally controlled
Pneumatic connection Internal thread G1/8
Operating pressure 0.6 MPa … 1 MPa
Operating pressure 6 bar … 10 bar
Operating pressure 87 psi … 145 psi
Medium Vapor – Hydraulic fluid based on mineral oil
Inert gas – Mineral oil – Water
Filtered compressed air, 200 µm filter mesh
Neutral liquids
Flow direction Under valve seat, for gaseous and liquid media
Max. viscosity 600 mm²/s
Temperature of medium -40 °C … 200 °C
Ambient temperature -10 °C … 60 °C
Flow rate Kv 3.3 m³/h
Valve housing material Cast stainless steel
Material number, fitting housing 1.4408
Spindle seal material PTFE
Seat seal material PTFE
Product weight 1,300 g
Corrosion resistance class (CRC) 2 – Moderate corrosion stress
Drive housing material Brass, nickel-plated

XC SERIES STAINLESS STEEL BEVEL VALVE – Angle seat valve
Port size DN10-DN50 Thread G1/4 G2″
Welded DIN11850 2 DIN11850 3 lSO2037
Valve bodv CF8M
Actyator CF8
Seat seals PTFE

Structural design Poppet valve with piston actuator
Actuation type Pneumatic
Sealing principle Soft
Type of mounting Line installation
Cable connection Threaded sleeve 1 NPT as per ANSI/ASME B 1.20.1
Nominal width 13 mm
Valve function 2/2, closed, monostable
Flow direction Non-reversible
Medium pressure 0 MPa … 4 MPa
Medium pressure 0 bar … 40 bar
Nominal pressure of fitting PN 40
Exhaust air function Without flow control option
Reset method Mechanical spring
Type of control Externally controlled
Pneumatic connection Internal thread G1/8
Operating pressure 0.6 MPa … 1 MPa
Operating pressure 6 bar … 10 bar
Operating pressure 87 psi … 145 psi
Medium Vapor – Hydraulic fluid based on mineral oil
Inert gas – Mineral oil – Water
Filtered compressed air, 200 µm filter mesh
Neutral liquids
Flow direction Under valve seat, for gaseous and liquid media
Max. viscosity 600 mm²/s
Temperature of medium -40 °C … 200 °C
Ambient temperature -10 °C … 60 °C
Flow rate Kv 3.3 m³/h
Valve housing material Cast stainless steel
Material number, fitting housing 1.4408
Spindle seal material PTFE
Seat seal material PTFE
Product weight 1,300 g
Corrosion resistance class (CRC) 2 – Moderate corrosion stress
Drive housing material Brass, nickel-plated

XMFZ RIGHT ANGLE PULSE VALVE
Adopt international advanced technology.
Used for dust remover.
Key parts all made of imported materiaIs.
Pneumatic control type,solenoid control type,ex-proof solenoid control type for choose
Female thread connection port,easy to be mounted.

Working Pressure 0.3~0.8MPa
Ambient Temperature -5~55℃
Relatively Humidity ＜85%
Working Medium Clean Air
VoItage AC110V/AC220V/DC24V
Diaphragm Life Cycles Over 1000k Cycles

Structural design Angled version
Diaphragm valve Actuation type
Electrical Sealing principle
Soft Mounting position
Any Type of mounting
Screwed tightly With thread
Process valve connection 1 1/4” ~ G2
Nominal width 50 mm
Valve function 2/2, closed, monostable
Manual override None
Flow direction Non-reversible
Differential pressure 0.35 bar
Reset method Mechanical spring
Type of control Pilot-controlled
Medium pressure 0.35 bar … 8 bar
Information on operating and pilot media Operation with oil lubrication not possible
Ambient temperature -20 °C … 60 °C
Flow rate Kv 78 m³/h
On switching time ≤ 30 ms
Switching time off ≤ 100 ms
Housing material Die-cast aluminum
Material number of housing EN AC-47100D
Seals material NBR
Material of screws High-alloy stainless steel
Material number of screw 1.4301
Armature tube material High-alloy steel
Diaphragm material NBR-PA
Product weight 2,800 g
Degree of protection IP65
Corrosion resistance class (CRC) 3 – high corrosion stress
Max. tightening torque for connecting thread 300 Nm

2S SERIES 2/2 WAY SOLENOID VALVE

Working Medium Air,Water,Oil,Gas
Motion Pattern Direct Drive Type
Type Normal Close Type
Operation Fluid Viscosity 20 CST(Below)
Max. Pressure Resistance MPa 1.0
Operating Temperature ℃ -5 ~ 80℃
